Pantographs

Sécheron SPL pantographs are the current collector of choice for tramway and Light Rail Vehicle (LRV) operators seeking reliable performance backed by expert service worldwide.

Documentations
Quotation Request

Product environment

Tramway and Light Rail Vehicle (LRV) operators turn to Sécheron for efficient, reliable current collectors. Our SPL pantograph is lightweight and features an extremely flat, yet stiff, design. A unique panhead suspension system ensures excellent dynamic behaviour and a very reliable electrical contact between the pantograph and the overhead line, as well as a longer carbon strip lifetime. The SPL pantograph has proven its superior performance in a variety of weather and operating conditions on tramway systems across Europe.

Sécheron can deliver the SPL pantograph on its own or together with other Sécheron electrical safety, measurement, and traction control components and solutions. Our DC circuit breaker type UR, completed with our BMS contactor range are typical products that will help you to design safe and reliable traction equipment.

Whether you are a transportation system operator or rail vehicle builder, you can count on Sécheron’s experts for support throughout your project. We can recommend the most appropriate solution for your unique situation and, once your solution is in service, we deliver local after-sales service during your products’ lifespan.

Quotation Request
Technical Description
  • Rated Voltage up to 1800 VDC.
  • Maximum working height above roof: 3300 mm (SPL30) / 2900 mm (SPL26).
  • Maximum running speed 100 km/h.
  • Maximum static contact force 120 N.
  • Rated / peak currents 1000 A / 1500 A.
  • Standstill current 200 A.
  • Overvoltage category OV4.
  • Electric actuator.
  • Control voltage 24 VDC, 36/37.5 VDC.
  • High mechanical durability.
  • Outdoor installation.
  • Suitable for ambient temperature – 25 °C to +40 °C.
  • Reference standards: EN 50126-2 / IEC 60494-2.
  • Insulation material according to EN 45545-2.

Main benefits

Wide working range
Very flat yet stiff design
Reliable contact with overhead lines
Service record
Low maintenance
Extensive factory reliability testing
Expert customer support
Worldwide after-sales service
